• Frequency: 9.2 – 9.5 GHz

• Polarization: Horizontal

• Vertical beam width: +12.5 degrees

• Azimuth beam width: Omnidirectional up to ±2dB

• Radiated power: > 400mW (+26dBm)

• Scanning mode: Sawtooth (12 scans)

• Pulse generation: < 100㎲

• Forward scanning time: 7.5㎲ ± 1㎲

• Scan return time: 0.4㎲ ± 0.1㎲

• Recovery time: < 10㎲ • Response time: < 0.5㎲

• Effective sensitivity: better than -50dBm

• Operating time: 96 hours in standby mode, then transmit for a minimum of 8 hours while in operation. continuously interrogated by X-band radar with 1KHz pulse repetition frequency at extreme temperatures

• Battery life: 5 years • Temperature range: Operation -20oC to 55oC, Storage -30oC to 65oC
​
